IMD170 Series: 17-inch Rugged Industrial Panel PC
Fanless, IP65-Rated Industrial Computer for HMI/SCADA & 24/7 Automation
Overview
Engineered for uncompromising reliability in the world's most demanding industrial environments, the IMD170 Series 17-inch industrial panel PC represents the pinnacle of rugged computing. This fanless panel PC combines a high-brightness display with a robust, sealed aluminum chassis to deliver continuous operation where it matters most—on your factory floor.
At its core, the Intel Celeron J1900 quad-core processor provides ample power for complex HMI/SCADA visualization, data acquisition, and control logic. The IP65 industrial computer front panel ensures complete protection against dust, water jets, and chemical exposure, making it ideal for wash-down areas, food processing plants, and heavy manufacturing. Its ultra-slim profile and versatile mounting options facilitate seamless OEM integration into machinery, control cabinets, and kiosks.
Key Features & Industrial Benefits
True Fanless & Rugged Design
Eliminates moving parts for superior reliability. The solid-state construction and wide operating temperature range (-10°C to 60°C) guarantee 24/7 uptime in environments with extreme temperatures, vibration, and particulate contamination.
IP65 Sealed Front Bezel
The IP65 industrial computer rating provides complete protection against dust ingress and low-pressure water jets from any direction. This allows for safe cleaning with high-pressure hoses and reliable operation in humid, wet, or dirty conditions.
Optimized for HMI/SCADA Software
Pre-validated compatibility with leading industrial software platforms, including Ignition SCADA by Inductive Automation. This embedded industrial computer serves as a powerful, dedicated edge node for visualization, data logging, and MES connectivity.
High-Brightness Industrial Display
The 17" SXGA (1280x1024) TFT LCD delivers a crisp, clear image with 300 nits brightness and wide viewing angles, ensuring excellent readability even in brightly lit facilities or from oblique angles.
Technical Specifications
| Category | Specification |
|---|---|
| Display | 17.0" TFT LCD, 1280 x 1024 (SXGA), 300 cd/m², 1000:1 Contrast Ratio |
| Touchscreen | Projected Capacitive (10-point multi-touch) or 5-Wire Resistive (Single-touch) |
| Processor | Intel Celeron J1900 Quad-Core Processor, 2.0GHz (Burst up to 2.41GHz) |
| Memory | 4GB DDR3L SODIMM (User-Expandable to 8GB) |
| Storage | 64GB mSATA SSD (Options available up to 512GB) |
| I/O Connectivity |
2 x USB 3.0, 2 x USB 2.0, 2 x RS-232/422/485 (Software-Selectable), 1 x Gigabit LAN (Intel i211AT), 1 x HDMI, 1 x VGA, Line-out, 2 x Internal Mini-PCIe |
| Power Input | 12~36V DC Wide-Range Input with Lockable DC Jack; 18W Typical Consumption |
| Operating System | Windows 10 IoT, Linux (Ubuntu, CentOS, Debian) |
| Physical Dimensions | 414mm (W) x 345mm (H) x 63mm (D) |
Environmental Ratings & Durability
Built to withstand the rigors of industrial life, the IMD170 Series is more than just a rugged touchscreen PC—it's a mission-critical asset.
- IP65 Front Seal: Fully protected against dust and water, enabling operation and cleaning in wash-down areas.
- Wide Temperature Operation: Functions flawlessly from -10°C to 60°C, ensuring startup in cold warehouses and stability in hot factory settings.
- Fanless Cooling: No internal fans eliminates a common point of failure, prevents dust accumulation, and allows for silent operation.
- Vibration & Shock Resistant: Robust construction and solid-state storage withstand typical industrial vibrations and minor impacts.
Software & Compatibility
This industrial HMI panel is designed for seamless integration into your automation ecosystem.
Ignition SCADA & Inductive Automation HMI: The IMD170 is an ideal hardware platform for Ignition SCADA edge-of-network deployments. Its x86 architecture, stable Windows/Linux OS support, and robust I/O meet the demands of Inductive Automation's powerful software for supervisory control, data acquisition, and IIoT connectivity.
Broad OS and Platform Support: Compatible with a wide range of industry-standard HMI and SCADA software packages, including (but not limited to) Siemens WinCC, Rock FactoryTalk View, GE iFIX, AVEVA System Platform, and CODESYS. Its standard interfaces ensure easy connection to PLCs, motor drives, and other industrial controllers.
Industrial Applications
Factory Automation & HMI
Machine control interfaces, production line monitoring, and operator stations.
SCADA Visualization
Local operator panels for water/wastewater, oil & gas, and energy management systems.
OEM Machine Integration
Embedded into industrial machinery, packaging equipment, and automated test systems.
Logistics & Warehousing
Inventory management, forklift terminals, and shipping/receiving station computers.
Certifications & Compliance
The IMD170 Series meets or exceeds stringent international standards, ensuring safety, quality, and global market acceptance.
| Certification | Description & Customer Benefit |
|---|---|
| ISO Certified | Manufactured under a certified Quality Management System (ISO 9001), ensuring consistent product quality and reliability. |
| FCC Compliant | Meets US electromagnetic interference standards, preventing disruption to other electronic equipment. |
| CE Marked | Confirms compliance with EU health, safety, and environmental protection legislation, allowing for sale in the European Economic Area. |
| RoHS Compliant | Restricts the use of hazardous substances (e.g., lead, mercury), making the product safer for the environment and end-of-life disposal. |
| UL Listed | Indicates the product has been independently tested by Underwriters Laboratories (USA) and meets specific safety standards. |
| cUL Certified | Certified to Canadian safety standards, often a requirement for industrial equipment installed in Canada. |
| IEC 60068 | Complies with international standards for environmental testing, verifying robustness against shock, vibration, and temperature extremes. |
