18.5" all-in-one Panel PC, 1920x1080, Intel core i5

18.5" all-in-one Panel PC, 1920x1080, Intel core i5

BASIC CONFIGURATION (REQUIRED)


TouchscreenCapacitive
Screen BrightnessStandard
Operating SystemNone

OTHER CONFIGURATIONS (OPTIONAL)


Power InputDirect DC(12VDC-36VDC)
Mounting
Mounting Instruction Video
Panel Mount
Upload Customer Specification Documentations

DISPLAY CONFIGURATIONS (OPTIONAL)


Display Bonding
Learn More
None
Auto Brightness SensorNone
Screen Film AddonNone

PC CONFIGURATIONS (OPTIONAL)


CPUDefault(See Specification)
MemoryDefault(See Specification)
Storage(SSD)Default(See Specification)
WiFi + BluetoothNone
Cellular ConnectivityNone
TouchScreen BehaviorStandard
Auto Power OnEnabled
Requested Delivery Date

Low stock: 2 left

SKU:IMD185-W210-I5-SD-NONE

$1,639.85 USD
$1,639.85 USD
STOCK Sold out
Shipping Calculated At Checkout

Please login to view the download links for the 3D Models.

View full details
18.5" 2nd Gen I Series Panel PC - Rugged & High-Performance fanless, IP65-rated, with Intel Core i5 and high-resolution display. Perfect for industrial applications.">

18.5" 2nd Gen I Series Panel PC - IMD185-W200-I5 Series

Overview

The 18.5 Inch 2nd Gen I Series Panel PC is designed for durability and efficiency in industrial environments. Featuring a fanless cooling system and IP65 protection, this panel PC excels in challenging settings, combining robust performance with advanced reliability. Its ultra-slim aluminum alloy frame ensures a sleek yet sturdy design for embedded installations.

Key Features

  • 18.5" Full HD TFT LCD with 1920×1080 resolution
  • Touchscreen options: capacitive, resistive, or non-touch
  • Fanless cooling system for reduced maintenance
  • IP65-rated front panel for water and dust resistance
  • Supports Intel Core i5 processors (multiple models)
  • Diverse I/O ports including HDMI, USB, RS232, and LAN
  • Vibration and impact protection per IEC standards
  • Wide temperature range: -10°C to 60°C operating

Technical Specifications

  • Display: 18.5" TFT LCD, 1920×1080, 16.7M colors
  • Touch Options: Capacitive (10-point), resistive, or non-touch
  • Brightness: 300 cd/m²
  • Contrast Ratio: 1000:1
  • CPU: Intel Core i5 (models include I5-6200U, I5-7200U, I5-8265U, I5-10210U)
  • RAM: 4GB DDR4 (upgradable to 64GB)
  • Storage: 128GB SSD (optional upgrades to 256GB/512GB)
  • Operating Systems: Windows 7/10/11, Ubuntu, CentOS
  • Power Input: DC 12V–36V
  • Operating Temperature: -10°C to 60°C

Applications

  • Industrial automation and control
  • Manufacturing process monitoring
  • Outdoor kiosks and digital signage
  • Transportation systems
  • Healthcare equipment interfaces

Keywords: Industrial Displays, Touch Panels, IP65 Panel PC, Siemens Panel PC, Custom Panel PC for Retail Kiosks, Industrial Panel PC, Industrial All-in-One PC Touch Screen, Customizable Fanless Touchscreen PC, Custom Panel PC with IP65 Enclosure, Industrial Panel PC Manufacturers, Industrial Workstations

SPECIFICATION
Loading... Specification
DIMENSION/CUT-OUT
